Don’t know what that means?  Read on…

These are the only high school students in the nation manufacturing precision optics, and they are doing it during a summer immersion program this July in the East High School Optics Manufacturing Lab.

The scorecard:

“Yesterday, July 20, Alejandra’s optics measured 1/7th wave.”

i-8NC4zFk-X3
Congresswoman Louise Slaughter (center), a long time advocate for Rochester’s Optics and Photonics Industry pictured with Adele Ratcliff, Undersecretery for DOD Supply Chain and Manufacturing (second from Left) and the East High Manufacturing team, including teacher Paul Conrow (back row, forth from left)

“Today, Demier Hill’s part measured to 1/10th wave on the Zygo interferometer.”

What does that mean?

Surface flatness is a type of surface accuracy specification that measures the deviation of a flat surface such as that of amirror, window, prism, or plano-lens. This deviation can be measured using an optical flat, which is a high quality, highly precise flat reference surface used to compare the flatness of a test piece. When the flat surface of the test optic is placed against the optical flat, fringes appear whose shape dictates the surface flatness of the optic under inspection. If the fringes are evenly spaced, straight, and parallel, then the optical surface under test is at least as flat as the reference optical flat. If the fringes are curved, the number of fringes between two imaginary lines, one tangent to the center of a fringe and one through the ends of that same fringe, indicate the flatness error. The deviations in flatness are often measured in values of waves (λ), which are multiples of the wavelength of the testing source. One fringe corresponds to ½ of a wave. 1λ flatness is considered typical grade, λ/4 flatness is considered to be precision grade, and λ/20 is considered high precision grade.

These students are achieving professional level results in terms of surface flatness, and are on their way towards possible careers in the optics, photonics and imaging industry.

IMG_8435 IMG_8436 IMG_8439 IMG_8442
